Chapter 2 Installation and Wiring
Figure 20 - Gland Connection
Wiring Terminal Detail
The power, control, and ground wire capacity and the tightening torque
requirements are shown in Ta b l e 8
. The maximum number of connections
per terminal are shown in Ta b le 7
. As shown in Figure 21 all the terminals are
found in the wiring area. Access can be gained by removing the terminal access
cover plate.
