214 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Appendix B CIP Information
Discrete Input
Group Object
CLASS CODE 0x001D
No class attributes will be supported for the Discrete Input Group (DIP) Object.
A single instance of the Discrete Input Group Object is supported and contains
the following instance attributes:
The following common services will be implemented for the Discrete Input
Group Object:
Discrete Output
Group Object
CLASS CODE 0x001E
No class attributes will be supported for the Discrete Output Group (DOP)
object.
Instance 1
…3 exists for all ArmorStart LT units.
Instance 1 exists for the sole purpose of providing a place holder for the Comm
Override and Network Override parameters. Instance 1 will contain the
following attributes:
Instance 2 controls the communication fault and idle behaviors for run/jog
outputs. Instance 2 contains the following instance attributes:
Attribute ID Access Rule Name Data Type Value
3 Get Number of Instances USINT 6
4 Get Binding Array of UINT List of DIP Instances
6 Get/Set Off_On_Delay UINT —
7 Get/Set On_Off_Delay UINT —
Service Code
Implemented for:
Service NameClass Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
3 Get Number of Instances USINT
8 for DOL/Soft Starter (Bulletin 290E/291E)
12 for Inverters (Bulletin 294E)
4 Get Binding Array of UINT List of DOP Instances
6 Get/Set Command BOOL 0 = Idle, 1 = Run
104 Get/Set Network Status Overrride BOOL
0 = No override (go to safe state)
1 = Override (run local logic)
105 Get/Set Comm Status Overrride BOOL
0 = No Override (go to safe state)
1 = Override (run local logic)
