26 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Chapter 1 Product Overview
Catalog Number Explanation
Examples given in this section are for reference purposes. This basic explanation
should not be used for product selection; not all combinations will produce a
valid catalog number.
294 E - F D1P5 Z - G1 - Option 1 - Option 2
——————————
abc d ef g h
a
Bulletin Number
Code Description
294 VFD Starter
b
Communications
Code Description
E EtherNet/IP
D DeviceNet
c
Enclosure Type
Code Description
F UL Type 4/12 ➊
d
Output Current
Code Description
D1P5 1.5 A (0.4 kW), 0.5 Hp
D2P5 2.5 A (0.75 kW), 1.0Hp
D4P2 3.6 A (1.5 kW), 2.0Hp
e
Control Voltage
Code Description
Z External 24V DC control power
PInternal power supply
f
Gland Plate Options
(Power and Motor)
Code Description
G1 Conduit entry
G2 ArmorConnect
G3 Gland kits ➋
g
Option 1
Code Description
3 Hand/Off/Auto selector keypad with Jog
function
h
Option 2
Code Description
SB Source Brake
blank
➌
No option
➊ IP66/UL Type 4 is available with all gland options. UL Type 4/12 is available with G1 and G3 gland option.
➋ See selection guide 290-SG001_-EN-P Accessories section for gland configurations and ordering.
➌ Leave blank unless there is a customer-specific option defined by the factory.
