Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 203
CIP Information Appendix B
Connection Manager Object
CLASS CODE 0x0006
No class attributes will be supported for the Connection Manager Object.
One Instance of the Connection Manager Object will be supported. It has the
following attributes:
11 Pt15DeviceOut Pt14DeviceOut Pt13DeviceOut Pt12DeviceOut Pt11DeviceOut Pt10DeviceOut Pt09DeviceOut Pt08DeviceOut
12 An00DeviceOut (low byte)
13 An00DeviceOut (high byte)
14
Parameter 3 – OutputCurrent
15
16
Parameter 4 – OutputVoltage
17
18
Parameter 5 – DCBusVoltage
19
20
Parameter 11 – SwitchedVolts
OutputSourceV (IPS units)
21
22
Parameter 12 – UnswitchedVolts
SensorSourceV (IPS units)
23
24
Parameter 13 – InternalFanRPM
25
26
Parameter 14 – ElaspedRunTime
27
28
Parameter 15 – DriveTemperature
29
30
Parameter 16 – TripStatus
31
32
Parameter 17 – WarningStatus
33
Instance 156 "Drive Status" – Produced Assembly for Bulletin 294E Starters
Attribute ID Access Rule Name Data Type Value
1 Set Open Requests UINT Number of Forward Open service requests received
2 Set Open Format Rejects UINT Number of Forward Open service requests which were rejected
due to bad format
3 Set Open Resource Rejects UINT Number of Forward Open service requests which were rejected
due to lack of resources
4 Set Open Other Rejects UINT Number of Forward Open service requests rejected for reasons
other than bad format or lack of resources.
5 Set Close Requests UINT Number of Forward Close service requests received
6 Set Close Format Requests UINT Number of Forward Close service requests which were rejected
due to bad format
