202 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Appendix B CIP Information
Instance 154
Instance 154 is the default Output (Consumed) Assembly for Inverter type
(Bulletin 294E) Distributed Starters.
Instance 156
Instance 156 is the Exhaustive Drive Status Assembly Instance
22
Parameter 11 – SwitchedVolts
OutputSourceV (IPS units)
23
24
Parameter 12 – UnswitchedVolts
SensorSourceV (IPS units)
25
26
Parameter 16 – TripStatus
27
28
Parameter 17 – WarningStstus
29
Instance 152 "Starter Stat" – DeviceLogix Produced Assembly for Bulletin 290E/291E Starters
Instance 154 "Drive Cmd" – DeviceLogix Consumed Assembly for Bulletin 294E Starters
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 JogReverse JogForward ResetFault RunReverse RunFoward
1 Decel2 Accel2 Out05 Out04 Out03 Out02 Out01 Out00
2 CommandFreq (Low) (xxx.x Hz)
3 CommandFreq (High) (xxx.x Hz)
4 Pt07DeviceIn Pt06DeviceIn Pt05DeviceIn Pt04DeviceIn Pt03DeviceIn Pt02DeviceIn Pt01DeviceIn Pt00DeviceIn
5 Pt15DeviceIn Pt14DeviceIn Pt13DeviceIn Pt12DeviceIn Pt11DeviceIn Pt10DeviceIn Pt09DeviceIn Pt08DeviceIn
6 An00DeviceIn (lowbyte)
7 An00DeviceIn (highbyte)
Instance 156 "Drive Status" – Produced Assembly for Bulletin 294E Starters
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved
1 Reserved
2Reserved
3Reserved
4 AtReference NetRefStatus NetControlStatus Ready RunningReverse RunningForward WarningPresent TripPresent
5 BrakeStatus DisconnectClosed KeyPadJogging KeyPadHand KeyPadOff KeyPadAuto DLXEnabled
6 Output Frequency (Low) (xxx.x Hz)
7 Output Frequency (High) (xxx.x Hz)
8 Pt05 Pt04 Pt03 Pt02 Pt01 Pt00
9
10 Pt07DeviceOut Pt06DeviceOut Pt05DeviceOut Pt04DeviceOut Pt03DeviceOut Pt02DeviceOut Pt01DeviceOut Pt00DeviceOut
