Chapter 1 Product Overview
Catalog Number Explanation
Examples given in this section are for reference purposes. This basic explanation
should not be used for product selection; not all combinations will produce a
valid catalog number.
290 E - F A Z - G1 - Option 1 - Option 2
—————— —— ——
abcdef g h
a
Bulletin Number
Code Description
290 Full-Voltage Starter
291 Reversing Starter
b
Communications
Code Description
E EtherNet/IP
D DeviceNet
c
Enclosure Type
Code Description
F UL Type 4/12 ➊
d
Overload Selection
Code Description
A 0.25…3.5 A
B 1.1…7.6 A
e
Control Voltage
Code Description
Z External 24V DC control power
PInternal power supply
f
Gland Plate Options
(Power and Motor)
Code Description
G1 Conduit entry
G2 ArmorConnect
G3 Gland Kits ➋
g
Option 1
Code Description
3 Hand/Off/Auto selector keypad
3FR Hand/Off/Auto selector keypad with
Forward/Reverse
h
Option 2
Code Description
blank
➌
No option
➊ IP66/UL Type 4 is available with all gland options. UL Type 4/12 is available with G1 and G3 gland option.
➋ See selection guide 290-SG001_-EN-P Accessories section for gland configurations and ordering.
➌ Leave blank unless there is a customer-specific option defined by the factory.
