Allen-Bradley ArmorStart 294E User Manual

222 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Appendix B CIP Information
DPI Alarm Object
CLASS CODE 0x0098
This object provides access to warning information within the device.
The following class attributes will be supported.
A single instance of the DPI Alarm Object will be supported.
The following common services will be implemented for the DPI Fault Object.
The table below lists Fault Codes, Fault Text, and Fault Help Strings.
Attribute ID Access Rule Name Data Type Value
1 Get Class Revision UINT 1
2 Get Number of Instances UINT 1
3 Set Alarm Cmd Write USINT 0=NOP; 1=Clear Alarm; 2=Clear Queue
74 Get Alarm Instance Read UINT
The instance of the Fault Queue Entry containing information
about the fault that tripped the device.
6 Get Number of Recorded Alarms UINT The number of faults recorded in the fault queue.
Attribute ID Access Rule Name Data Type Value
0GetFull/All Info
Alarm Code
Alarm Source
DPI Port Number
Device Object Instance
Alarm Text
Alarm Time Stamp
Timer Value
Timer Descriptor
Help Object Interface
Alarm Data
Struct of:
UINT
Struct of:
USINT
USINT
STRING
Struct of:
ULINT
WORD
USINT
See Tables below
0
See Tables below
1GetBasic Info
Alarm Code
Alarm Source
DPI Port Number
Device Object Instance
Alarm Time Stamp
Timer Value
Timer Descriptor
Struct of:
UINT
Struct of:
USINT
USINT
Struct of:
ULINT
WORD
See Tables below
0
3 Get Help Text STRING See Tables below
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 Yes No Set_Attribute_Single
Table 35 - Fault Codes, Fault Text, and Fault Help Strings for ArmorStart LT
Warning
Code Warning Text Help Text
1Warning 1 —
2Warning 2 —
3 Motor Overload Overload warning level has been exceeded.
