Discrete Input Point
Object
CLASS CODE 0x0008
The following class attributes are currently supported for the Discrete Input
Point Object:
Six instances of the Discrete Input Point Object are supported. All instances
contain the following attributes:
The following common services will be implemented for the Discrete Input Point
Object:
Discrete Output Point
Object
CLASS CODE 0x0009
The following class attributes are supported:
fo
0x10 No Yes Set_Attribute_Single
0x4E No Yes Forward_Close
0x54 No Yes Forward_Open
Service Code
Implemented for:
Service NameClass Instance
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 2
2 Get Max Instance UINT 6
Attribute ID Access Rule Name Data Type Value
3 Get Value BOOL 0 = OFF, 1 = ON
4 Get Fault Status BOOL 0 = OK, 1 = Fault
115 Get/Set Force Enable BOOL 0 = Disable, 1 = Enable
116 Get/Set Force Value BOOL 0 = OFF, 1 = ON
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instance UINT 8 for Bulletin 290E/291E, 10 for Bulletin 294E
