Appendix B CIP Information
➊ Reversing Starters (291E) and Inverter (294E) Starters only
The following common services will be implemented for the Control Supervisor
Object.
Overload Object
CLASS CODE 0x002C
No class attributes will be supported for the Overload Object.
A single instance (Instance 1) of the Overload Object is supported for DOL
(Bulletin 290E/291E) and Reversing (Bulletin 294E) Starters. Instance 1
contains the following instance attributes.
Attribute ID Access Rule Name Data Type Value
3 Get/Set Run 1 BOOL
These Run outputs also map to DOP Instances 1 and 2
4
➊ Get/Set Run 2 BOOL
7 Get Running 1 BOOL —
8➊ Get Running 2 BOOL —
9 Get Ready BOOL —
10 Get Tripped BOOL —
12 Get/Set Fault Reset BOOL 0 > 1 = Trip Reset
Service Code
Implemented for:
Service NameClass Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
3 Get/Set FLA Setting BOOL xxx.x amps
4 Get/Set Trip Class USINT —
5 Get Average Current INT xxx.x amps
7 Get % Thermal Utilized USINT xxx% FLA
8 Get Current L1 INT
xxx.x Amps9 Get Current L2 INT
10 Get Current L3 INT
190 Get/Set FLA Setting Times 10 BOOL
xxx.xx Amps
192 Get Average Current Times 10 UINT
193 Get Current L1 Times 10 UINT
194 Get Current L2 Times 10 UINT
195 Get Current L3 Times 10 UINT
