Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 99
Chapter 4
Bulletin 290E/291E/294E
Programmable Parameters
Electronic Data Sheet (EDS)
When a 3rd party PLC is used, an embedded EDS file can be uploaded directly
from the ArmorStart LT. This allows device configuration through 3rd party
tools. EDS files are also available on the internet at: http://www.ab.com/
networks/eds.
Basic Setup Parameters
When the RSLogix AOP is not used, Table 22 lists the minimum setup
configurations required for Bulletin 290E/291E or Bulletin 294E. Basic
parameter configuration, status, and diagnostic information can be accessed
from the embedded web browser.
RSLogix 5000 is the recommended commissioning software. Download the Add-
On-Profile (AOP) from http://support.rockwellautomation.com/controlflash/Logix
Profiler.asp for additional functionality. There are additional capabilities that are
not enabled or left at their default values.
➊ When using the AOP this parameter is configured during module definition on the “General” page.
Table 22 - Quick Parameter Setup
Bulletin 290E/291E Bulletin 294E
28 FLASetting
29 OLResetLevel
30 OverloadClass
49 IOPointConfiguration
28 MotorNPVolts
29 MotorNPHertz
30 MotorOLCurrent
32 StopMode
34 MinimumFreq
35 MaximumFreq
36 AccelTime1
37 DecelTime1
49 IOPointConfiguration➊
All I/O points are configured as inputs, by default. Identify which points
are outputs, when needed for proper operation, using parameter 49
[IOPointConfiguration].
