Chapter 1 Product Overview
Fault Diagnostics
Fault diagnostics capabilities built in the ArmorStart LT Distributed Motor
Controller are designed to help you pinpoint a problem for easy troubleshooting
and quick re-starting.
Protection Faults
Protection faults will be generated when potentially dangerous or damaging
conditions are detected. Protection faults are also known as “trips” or “faults”.
These faults will be reported in multiple formats, including:
• Bit enumeration in the TripStatus parameter 16 in DeviceLogix
• In the ArmorStart LT web server for ArmorStart EtherNet/IP version
• As a sequence of LED flashes on the ECM
Table 6 - Protection Faults
➊ Cannot be disabled.
LED Flash Bit Enumeration Bulletin 290E/291E Trip Status Bits Bulletin 294E Trip Status Bits
10OverloadTrip ➊ OverloadTrip ➊
2 1 PhaseLossTrip PhaseLShortTrip
32UnderPowerTrip ➊ UnderPowerTrip ➊
4 3 SensorShortTrip ➊ SensorShortTrip ➊
5 4 PhaseImbalTrip OverCurrentTrip
65NonVolMemoryTrip ➊ NonVolMemoryTrip ➊
76reserved ParamSyncTrip ➊
8 7 JamTrip DCBusOrDiscnnct ➊
98StallTrip StallTrip ➊
10 9 UnderloadTrip OverTemperature ➊
11 10 reserved GroundFault ➊
12 11 reserved RestartRetries
13 12 reserved DriveHdwFault ➊
14 13 OutputShortTrip ➊ OutputShortTrip ➊
15 14 UserDefinedTrip UserDefinedTrip
16 15 HardwareFltTrip ➊ HardwareFltTrip ➊
