Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 201
CIP Information Appendix B
Instance 150
Instance 150 is the default Output (Consumed) Assembly for Bulletin 290E/
291E starters.
Instance 152
Instance 152 is the Exhaustive Starter Status Assembly for Bulletin 290E/291E
starters.
Instance 150 "Starter Cmd" – DeviceLogix Consumed Assembly for Bulletin 290E/291E Starters
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 — — — — — ResetFault RunReverse RunForward
1 — — Out05 Out04 Out03 Out02 Out01 Out00
2 Pt07DeviceIn Pt06DeviceIn Pt05DeviceIn Pt04DeviceIn Pt03DeviceIn Pt02DeviceIn Pt01DeviceIn Pt00DeviceIn
3 Pt15DeviceIn Pt14DeviceIn Pt13DeviceIn Pt12DeviceIn Pt11DeviceIn Pt10DeviceIn Pt09DeviceIn Pt08DeviceIn
4 AnalogDeviceIn (low byte)
5 AnalogDeviceIn (high Byte)
Instance 152 "Starter Stat" – DeviceLogix Produced Assembly for Bulletin 290E/291E Starters
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved
1 Reserved
2Reserved
3Reserved
4 CurrentFlowing NetControlStatus Ready RunningReverse RunningForward WarningPresent TripPresent
5 DisconnectClosed KeyPadHand KeyPadOff KeyPadAuto DLXEnabled
6 Pt05 Pt04 Pt03 Pt02 Pt01 Pt00
7
8 Pt07DeviceOut Pt06DeviceOut Pt05DeviceOut Pt04DeviceOut Pt03DeviceOut Pt02DeviceOut Pt01DeviceOut Pt00DeviceOut
9 Pt15DeviceOut Pt14DeviceOut Pt13DeviceOut Pt12DeviceOut Pt11DeviceOut Pt10DeviceOut Pt09DeviceOut Pt08DeviceOut
10 An00DeviceOut (low byte)
11 An00DeviceOut (high byte)
12
Parameter 1 – PhaseL1Current
13
14
Parameter 2 – PhaseL2Current
15
16
Parameter 3 – PhaseL3Current
17
18
Parameter 4 – AverageCurrent
19
20
Parameter 5 – %ThermalUtilized
21
