Allen-Bradley ArmorStart 294E User Manual

108 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Chapter 4 Bulletin 290E/291E/294E Programmable Parameters
Bit
Function
1514131211109876543210
——————————————— X OverloadTrip
—————————————— X — PhaseLossTrip
————————————— X —— UnderPowerTrip
———————————— X ——— SensorShortTrip
——————————— X ———— PhaseImbalanceTrip
—————————— X ————— NonVolMemoryTrip
————————— X —————— Reserved
———————— X ——————— JamTrip
——————— X ———————— StallTrip
—————— X —————————
Underload Tri p
——— X X X —————————— Reserved
—— X ————————————— OutputShortTrip
— X —————————————— UserDefinedTrip
X ——————————————— HardwareFltTrip
WarningStatus
This parameter provides the current
warning condition.
Parameter Number 17
Access Rule GET
Data Type WORD
Group Trip Status
Units —
Minimum Value 0
Maximum Value 0xC295
Default Value
Bit
Function
1514131211109876543210
——————————————— X OverloadWarning
—————————————— X — Reserved
————————————— X ——
UnderPowerWarn
———————————— X ——— Reserved
——————————— X ———— PhaseImbalanceWarn
————————— X X ————— Reserved
———————— X ——————— JamWarning
——————— X ———————— Reserved
—————— X ————————— UnderloadWarning
——XXXX—————————— Reserved
— X —————————————— UnswitchedPwrWarn
X —————————————— ConfigWarning
