Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 225
CIP Information Appendix B
The following common services will be implemented for the Ethernet Link
Object.
4 Get Interface Counters Struct of:
In Octets
In Ucast packets
In NUcast packets
In Discards
In Errors
In Unknown Protos
Out Octets
Out Ucast packets
Out NUcast packets
Out Discards
Out Errors
5 Get Media Counters Struct of:
Alignment Errors
FCS Errors
Single Collisions
SQE Test Errors
Deferred Transmits
Late Collisions
Excessive Collisions
MAC Transmit Errors
Carrier Sense Errors
Frame Too Long
MAC Receive Errors
6 Get/Set Interface Control Struct of:
Control Bits
Forced Interface
Speed
7 Get Interface Type USINT
8GetInteface State USINT
9 Get/Set Admin State USINT
10 Get Interface Label SHORT_STRING Instance 1:LS 1
Instance 2:LS 2
Attribute ID Access Rule Name Data Type Value
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
