Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 169
Specifications Chapter 6
Standards Compliance and Certifications
Standards Compliance
UL/CSA EN/IEC Other Agencies
UL 508 Industrial Control Equipment –
Suitable for Group Installation
CSA C22.2, No. 14
EN 60947-4-1 Low Voltage Switchgear
CE Marked per Low Voltage Directive 2006/95/EC
and EMC Directive 2004/108/EC
CCC (Pending)
KCC
C-Tick
ODVA for EtherNet/IP and DeviceNet
Certifications cULus (File No. E3125, Guide NLDX, NLDX7)
Communication Ratings
Rated Insulation Voltage 250V
Operating Dielectric Withstand UL/NEMA: 1500V AC, IEC: 2000V AC
EtherNet/IP
EtherNet/IP ODVA – Conformance Testing EtherNet/IP Interoperability Performance – Per A9 PF 2.1
Ethernet Communication Rate 10/100 Mbps, half or full-duplex
Ethernet Ports 2 (embedded switch)
Ethernet Network Topologies Supported Star, Tree, Linear, and Ring
Device Level Ring Support Beacon Performance, IEEE 1588 Transparent Clock
Ethernet Connector M12, D code, female, with Ethernet keying, 4 Pin
Ethernet Cable Category 5e: Shielded or unshielded
IP Configuration Static, DHCP, or BootP
DHCP Timeout 30 s
Data Transported over both TCP and UDP
Packet Rate (pps)
500 packets-per-second (2000 μs), Tx
500 packets-per-second (2000 μs), Rx
Consume Instance (Command) Default of 3 words (Instance 150)
Produce Instance (Status) Default of 14 words (Instance 152)
Message Support Unicast or Multicast
Address Conflict Detection (ACD) IP v4 Address Conflict Detection for EtherNet/IP devices
Sockets 150 maximum
Web Server
Security Login and password configurable
E-mail Support Simple Mail Transfer Protocol (SMTP)
Webpage Features Status, diagnostics, configuration
Concurrent Sessions 20
Web Server HTTP 1.1
Network Connections
Concurrent TCP Connections Maximum of 15 encapsulated messages over both TCP and UDP
Maximum I/O Connections (CIP Class 1)
Supports up to 2 Class 1 CIP connections [Exclusive owner (data) or
listen-only]. One connection per PLC. Listen only connection requires a
data connection to be established.
Maximum Concurrent Explicit Messages (CIP Class 3) 6
Class 1 Connection API 2…3200 ms
Class 3 Connection API 100…10 000 ms
Request Packet Interval (RPI) 20 ms default (2 ms minimum)
