168 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Chapter 6 Specifications
Environmental Ratings
Operating Temperature Range -20…+50 °C (-4…+122 °F)
Storage and Transportation Temperature Range -25...+85 °C (-13…+185 °F)
Altitude 2000 m
Humidity 5…95% (non-condensing)
Pollution Degree 3
Enclosure Ratings IP66/UL Type 4/12 ➊
Approximate Shipping Weight 4.6 kg (10 lb)
Mechanical Ratings
Resistance to Shock
Operational 30 G, exceeds IEC 60947-1
Non-Operational 50 G, exceeds IEC 60947-1
Resistance to Vibration
Operational 2.5 G, tested to MIL-STD-810G, exceeds IEC 60947-1
Non-Operational 5 G, tested to MIL-STD-810G, exceeds IEC 60947-1
Disconnect Lock Out Maximum of 3/8 in. (9.5 mm) diameter lock shackle or hasp
Disconnect LOTO Locks Up to 2 locks or hasps are supported
Disconnect Mechanical Life 200 000 operations
Contractor Utilization Category
(IEC)
AC-1, AC-3, AC-4 (refer to Life Load Curves)
Contactor Opening Delay 8…12 ms
Contactor Closing Delay 18…40 ms
Minimum Off Time 200 ms
Contactor Mechanical Life 15 million operations
Power Terminals Motor Terminals Control Terminals PE/Ground
Wire Size➋
(2) #18 …#10 AWG
(0.8…5.2 mm
2
) per terminal
#18…#10 AWG
(0.8…5.2 mm
2
) per terminal
(2) #18 …#10 AWG
(0.8…5.2 mm
2
) per terminal
(2) #16 …#10 AWG
(1.3…5.2 mm
2
) per terminal
Wire Type Multi-strand copper wire
Tightening Torque 10.6 ± 2 lb•in (1.2 ± 0.2 N•m) 18 ± 2 lb•in (2 ± 0.2 N•m)
Wire Strip Length 0.35 ± 0.01 in. (9 ± 2 mm)
Power Rating 600V AC/25 Amp 600 V AC/10 Amp 600 V AC/10 Amp —
Emission and Immunity Ratings
Emission
Conducted
EN 60947-4-1
Class A
Radiated
Electrostatic Discharge 4 kV contact, 8 kV air
Radio Frequency Electromagnetic Field
EN 60947-4-1
10V/m, 80 MHz…1 GHz
10V/m, 1.4 GHz…2 GHz
Immunity
Fast Transient
2 kV (Power)
2 kV (PE)
1 kV (Communication and control)
Surge Transient 1 kV (12)
L-L
, 2 kV (2)
L-N
(earth)
Radio Frequency Conducted Disturbance 10V, 150 kHz…80 MHz
➊ IP66/UL Type 4 is available with gland options G1-3. IP66/UL Type 4/12 available with G1 and G3 gland option
➋ When two wires used in terminal block both wires are to be of same wire AWG.
