Chapter 4 Parameters and Function Codes
P093Skip Frequency 3 Upper Limit0 75000000000000 On/OffYY P094Fan Control Mode 0 2000000000000 OfflineYY P095Fan Control Group #1 Fan Number0 10000000000000 OfflineYY P096Fan Control Group #2 Fan Number0 10000000000000 OfflineYY P097Fan Control Group #3 Fan Number0 10000000000000 OfflineYY P098Fan Control Group #4 Fan Number0 10000000000000 OfflineYY P099 Fan Control Main Cooling Fan Cycle
Time
0 14400 720 720 720 720 720 720 720 720 720 720 720 720 hr On/Off Y Y
P100 Fan Control Redundant Fan Working
Time
0 14400111111111111hrOn/OffYY
P101 Fan Control Fan Feedback Delay 0 1000 200 200 200 200 200 200 200 200 200 200 200 200 100ms On/Off Y Y P102Fan Control Fan Stop Delay 0 10111111111111mOn/OffYY P103 Pre-charge Enable
0 = Disable 1 = Enable
0 1000000000000 On/OffYY
P104Pre-charge Feedback Delay 0 100202020202020202020202020100 msOn/Off Y P105Pre-charge DC Bus Threshold 0 100808080808080808080808080%On/Off Y P106 Fan Control Transformer Cabinet Fan
Quantity Upper Limit
0 16101010101010101010101010 On/OffYY
P107 VFD Overload Current Offset 0.00 399.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 % On/Off Y P108 Motor Overload Current Offset 0.00 399.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 % On/Off Y P110 Heating Current Threshold 0.00 399.99 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 110.00 % On/Off Y P111 Slip Compensation Enable
0 = Disable 1 = Enable
0 1000000000000 On/Off Y
P113Flying Start-Initial Output Voltage0 100888888888888%On/OffYY P114 Flying Start-Current Comparison
Delay For Motor Speed Search
0 5000 500 500 500 500 500 500 500 500 500 500 500 500 ms On/Off Y Y
P115 Flying Start-Current Threshold For
Successful Motor Speed Search
0.00 100.00 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 4.99 On/Off Y Y
P116 Fan Control TX Cabinet Fan Fault Trip
Delay
1 60303030303030303030303030mOn/OffYY
P117 Fan Control Filter Cabinet Fan Fault
Trip Delay
1 60303030303030303030303030mOn/OffYY
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
