Rockwell Automation Publication 6000-UM002E-EN-P - April 2018 72
Parameters and Function Codes Chapter 4
P169 Line Short Circuit Fault Threshold 0 400 180 180 180 180 180 180 180 180 180 180 180 180 % On/Off Y Y
P170 Line Short Circuit Fault Delay 0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P171 Line Current Phase A Scaling Factor 0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/OffY
P172 Line Current Phase B Scaling Factor 0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/OffY
P173 Line Current Phase C Scaling Factor 0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/OffY
P174 Line Current Positive Sequence Filter
Time
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P175 Line Current Negative Sequence
Filter Time
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P176 Line Current Negative Sequence
Fault Threshold
0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 % On/Off Y Y
P177 Line Current Negative Sequence
Fault Delay
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y
P178Motor Autotune Rs Upper Limit0 100505050505050505050505050%On/Off Y
P179 Motor Autotune Maximum Iq For No
Load
0.00 399.99 30.00 30.00 30.00 30.00 30.00 30.00 30.00 30.00 30.00 30.00 30.00 30.00 % On/Off Y
P180 Pre-charge Resistor Short Circuit
Fault Threshold
0 10222222222222%On/Off Y
P181 Pre-charge Resistor Short Circuit
Fault Delay
0 10000 500 500 500 500 500 500 500 500 500 500 500 500 ms On/Off Y
P182 Derating Function Enable
0 = Disable
1 = Enable
0 1111111111111 On/Off
P183 Voltage Lower Threshold For Drive
Derating Per Cooling Fan Input
Voltage Drop
0 100 70 70 70 70 70 70 70 70 70 70 70 70 On/Off
P184 Voltage Upper Threshold For Drive
Derating Per Cooling Fan Input
Voltage Drop
0 100 75 75 75 75 75 75 75 75 75 75 75 75 On/Off
P185 Drive Output Current Upper
Limitation Per Cooling Fan Input
Voltage Drop
0 100 76 76 76 76 76 76 76 76 76 76 76 76 On/Off
P186 Drive Start Delay 0 32767 10000 10000 10000 10000 10000 10000 10000 10000 10000 10000 10000 10000 ms On/Off Y
P187Flying Start Voltage Threshold0 100333333333333 On/OffYY
P195Line CT Ratio 0 0000000000000 OfflineYY
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
