Allen-Bradley PowerFlex 6000 User Manual

73 Rockwell Automation Publication 6000-UM002E-EN-P - April 2018
Chapter 4 Parameters and Function Codes
P196Line CT Burden Resistor 0 0000000000000 OfflineYY P197 Motor HECS Ratio 0 9999.99 1000.00 1000.00 1000.00 1000.00 1000.00 1000.00 1000.00 1000.00 1000.00 1000.00 1000.00 1000.00 Offline Y Y Y P198 Motor HECS Burden Resistor 0 19.99 15 15 15 15 15 15 15 15 15 15 15 15 Offline Y Y Y P199 Motor Rated Current 0 5000 40 40 40 40 40 40 40 40 40 40 40 40 A Offline Y Y Y P200Ia Motor Current Memory Address0 500131313131313131313131313 On/Off Y P201 Motor Ia Scaling Factor 0.00 199.99 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 On/Off Y P202Ic Motor Current Memory Address0 500141414141414141414141414 On/Off Y P203 Motor Ic Scaling Factor 0.00 199.99 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 105.00 On/Off Y P204Motor Uab Voltage Address 0 500111111111111111111111111 On/Off Y P205 Motor Uab Voltage Scaling Factor 0.00 199.99 153.00 146.70 175.90 159.90 175.80 169.00 146.50 167.40 159.80 152.80 158.10 143.70 On/Off Y Y P206 Motor Uac Voltage Scaling Factor 0.00 199.99 153.00 146.70 175.90 159.90 175.80 169.00 146.50 167.40 159.80 152.80 158.10 143.70 On/Off Y Y P208 Phase Over Current Enable
Frequency Range Upper limit
0 100 10 10 10 10 10 10 10 10 10 10 10 10 On/Off Y
P209Phase Over Current Filter Time0 32767555555555555 On/Off Y P210 Phase Over Current Threshold 0.00 399.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 On/Off Y Y P211 Filter Time For Abnormal Output
Voltage
0 32767 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms On/Off Y
P212 Filter Time For Output Short-Circuit 0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y Y P213 Output Short-Circuit Fault Threshold 0.00 399.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 179.99 On/OffYY P214 Motor Minimum Overload Current 0.00 399.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 104.99 % On/Off Y Y P215 Motor Overload Cycle Time 0 32767 600 600 600 600 600 600 600 600 600 600 600 600 s On/Off Y Y P216 MotorOverload Trip Threshold 0.00 399.99 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 % On/Off Y Y P217 Motor Overload Time 0 32767 60 60 60 60 60 60 60 60 60 60 60 60 s On/Off Y Y P221 Filter Time For Output Over Voltage 0 32767 100 100 100 100 100 100 100 100 100 100 100 100 ms On/Off Y P222 Output Over Voltage Fault Threshold 0.00 199.99 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 On/Off Y Y
P223 Output Voltage Deviation Warning
Threshold
0.00 199.99 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 60.00 On/Off Y Y
P224 Output Voltage Deviation Fault
Threshold
0.00 199.99 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 80.00 On/Off Y Y
P226 Output Voltage Abnormality
Warning Cancellation Threshold
0.00 199.99 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 50.00 On/Off Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
