Parameters and Function Codes Chapter 4
P227 Ground Fault Detection Scaling
Correction Factor
0.00 199.99 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 On/Off Y
P228 Filter Time For Ground Fault 0 32767 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ms On/Off Y P229 Ground Fault Warning Threshold 0.00 199.99 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 8.00 On/Off Y P230 Ground Fault Trip Threshold 0.00 199.99 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 On/Off Y P231 Filter Time For Overspeed Fault
(Upper Limit)
0 32767 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P232 Filter Time For Overspeed Fault
(Lower Limit)
0 32767 100 100 100 100 100 100 100 100 100 100 100 100 On/Off Y
P233 Threshold Of Over-Speed Fault At
Lower Frequency Limit
0.00 199.99 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 On/Off Y
P234 Threshold Of Over-Speed Fault At
Upper Frequency Limit
0.00 199.99 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 20.00 On/Off Y
P235 Frequency Deviation Warning
Cancellation Threshold
0.00 199.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 On/Off Y
P236 Frequency Deviation Warning
Threshold
0.00 199.99 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 On/Off Y
P237Frequency Deviation Warning Delay0 327678888888888 8msOn/Off Y P238 Motor Stall Fault Threshold 0.00 199.99 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 On/Off Y Y P239 Motor Stall Fault Delay 0 32767 6000 6000 6000 6000 6000 6000 6000 6000 6000 6000 6000 6000 ms On/Off Y P240 Transformer Over Temperature Fault
Delay
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y
P241 Transformer Over Temperature
Warning Delay
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 ms On/Off Y
P250 Input Contactor/Circuit Breaker
Close Delay
0 32767 10000 10000 10000 10000 10000 10000 10000 10000 10000 10000 10000 10000 ms On/Off Y
P251 Frequency Command-Low
Frequency Region Boundary
0.0 100.0 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 On/Off Y
P252 Motor In Stopping Condition
Threshold
0 100111111111111 On/OffYY
P253 Motor Coast Stop Time 0 10000 10 10 10 10 10 10 10 10 10 10 10 10 On/Off Y Y P254 DC Bus Under Voltage Fault
Threshold
0 100 63 63 63 63 63 63 63 63 63 63 63 63 % On/Off Y
P256 Ground Fault Warning Cancellation
Threshold
0.00 199.99 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 5.00 On/Off Y
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
