120 Rockwell Automation Publication 20Y-TG001C-EN-P - April 2017
Appendix D Disassembly/Assembly Diagrams and Spare Parts
EMC cover N/A
Gate driver board 400/480V SK-Y1-GDB1-F10D
600/690V SK-Y1-GDB1-F10E
Power module 400/480V SK-Y1-QOUT-D460
600/690V SK-Y1-QOUT-E325
Power bus bar N/A
Screening plate (for gate driver board) N/A
Snubber capacitor assembly N/A
ATTENTION: The sheet metal cover and mounting screws on the ASIC Board
that is located on the power structure are energized at (-) DC bus potential
high voltage. Risk of electrical shock, injury, or death exists if someone comes
into contact with the assembly.
Table 14 - AFE Power Structure Assembly Internal Component Part Numbers (Continued)
Part Name Cat. No.
