5.4.1 Starting the single-phase thermal or electric engine (EVO versions)
For EVO versions it is now possible to operate the machine using the thermal engine or the single-phase
electric motor (if present) on the basis of the instructions in the previous chapters. Check the fuel level
before operating the thermal engine.
To power, the single-phase electric motor, an
electric cable must be connected to the socket on
the base carriage in the area indicated in the
image alongside.
It should be noted that with a single-phase
electric motor, all movements are slower than
normal speeds with a thermal engine.
When the single-phase electric pump is connected to the power supply, always check the position of
the power cable when moving.
Connect to an electrical network equipped with all the protections according to the safety standards
in force, and which has the following characteristics (depending on the country in which the machine
is put into service):
- Power supply voltage 115-230V AC ± 10% single phase;
- Frequency 50 ÷ 60 Hz;
- Ground line connected;
- Efficient magneto-thermal and differential switch device;
It is also necessary to keep in mind:
- Do not use cables or extensions longer than 5 meters;
- Do not use coiled cables or extensions;
- Use a cable with an appropriate section (minimum 3x2.5 mm²);
5.4.2 Starting the electric motor (ELC-LTH versions).
For ELC-LTH versions: It is now possible to operate the machine using the electric motor on the basis of
the instructions in the previous chapters.
