ALMACRAWLER JIBBI Series User Manual

PAGE48
2.4.5.4 JIBBI U-1570 working diagrams with reduced track 1.98 m. Translation inhibited.
Metric
Imperial
A
Maximum working height - 250 kg
12.9
m
42' 4''
ft
B
Maximum working height - 200 kg
13.9
m
45' 7''
ft
C
Maximum working height - 140 kg
15.2
m
50' 0''
ft
D
Maximum working outreach - 250 kg
5.3
m
17' 5''
ft
E
Maximum working outreach - 200 kg
5.9
m
19' 4''
ft
F
Maximum working outreach - 140 kg
6.6
m
21' 8''
ft
G
Maximum working outreach - 80 kg
7.8
m
25' 7''
ft
Metric
Imperial
A
Maximum working height - 250 kg
13.0
m
42' 8''
ft
B
Maximum working height - 200 kg
14.0
m
46' 0''
ft
C
Maximum working height - 140 kg
15.2
m
50' 0''
ft
D
Maximum working outreach - 250 kg
6.7
m
22' 0''
ft
E
Maximum working outreach - 80 kg
7.8
m
25' 7''
ft
5°
B
C
D
E
F
G
A
5°
D
E
A
B
C
