According to the periodicity described in the maintenance
table, it is necessary to check the oil level in the traction
reducers according to the following procedure.
To check the level:
- command the translation until the plugs (A) and
(B) are in the position shown alongside;
- Unscrew the cap (B);
- If you notice oil leaking, the level is correct.
Otherwise, proceed to top up through the cap (A)
until the oil comes out of (B).
To replace the gearbox oil:
- Control the translation until the caps (A) and (B1) are in the position shown alongside;
- Place a container under the cap (B1) capable of collecting the gearbox oil;
- Unscrew the caps (B1) and (A) and completely empty the reducer;
- Close the cap (B1) and pour lubricating oil for gearboxes into the hole (A) until it comes out of the
hole itself;
- Close the cap (A).
Use only the types of oil indicated in the table below.
