ALMACRAWLER JIBBI Series User Manual

PAGE20
2.1.3 Technical data version JIBBI 1250 EVO - YANMAR 3TNV74-SDSA.
Technical data
Metric
Imperial
Diesel engine type: Yanmar 3TNV74-SDSA
Certification
EPA Final Tier 4 - Stage V
Machine weight (1)
2880
kg
6350
lbs
Dry mass of the engine
124
kg
270
lbs
Displacement
993
cm³
60
in
3
Net power
14.2
kW
20
HP
Net power regime
3000
g/min
3000
rpm
Engine oil quantity
2.8
l
0.7
gal
Fuel tank capacity
24
l
6.2
gal
Starter battery voltage and capacity
12/54
V / Ah
12/54
V / Ah
Starter battery weight
12.1
kg
27
lbs
LWA sound power
104
dB A
104
dB A
Noise level of operator station Lp (internal industrial environment)
84.5 ± 2.6
dB A
84.5 ± 2.6
dB A
Noise level of operator station Lp (external environment on asphalt)
79.5 ± 2.6
dB A
79.5 ± 2.6
dB A
Maximum peak level Lp peak
106.0
dB C
106.0
dB C
Hand / arm system vibrations (operator hands support)
<2.5
m / s²
<2.5
m / s²
Whole Body Vibration (on platform - measured on level ground) (2)
0.52 ± 0.10
m / s²
0.52 ± 0.10
m / s²
Hand / arm system vibrations (operator hands support) (3)
0.59 ± 0.10
m / s²
0.59 ± 0.10
m / s²
Minimum operating temperature
-20
°C
-4
°F
Maximum operating temperature
+55
°C
+131
°F
Performance:
Max slope that can be overcome in transport conditions
25
°
25
°
Maximum transfer speed in transport position
2.5
km / h
1.6
mph
Maximum transfer speed with the platform in a high position
0.4
km / h
0.2
mph
Full platform rise time
60
s
60
s
Full platform descent time
40
s
40
s
Optional single-phase 230V 50Hz electric pump
Additional weight of the electric pump
30
Kg
65
lbs
Electric pump power
2.2
kW
3
HP
Regime
1400
g/min
1400
rpm
Maximum current absorbed from the mains
14
A
14
A
Optional single-phase 230V 60Hz electric pump
Additional weight of the electric pump
30
Kg
65
lbs
Electric pump power
1.5
kW
2
HP
Regime
1620
g/min
1620
rpm
Maximum current absorbed from the mains
9.9
A
10
A
Optional single-phase electric pump 110V 50Hz
Additional weight of the electric pump
30
Kg
65
lbs
Electric pump power
1.85
kW
2.5
HP
Regime
1400
g/min
1400
rpm
Maximum current absorbed from the mains
28
A
28
A
Optional single-phase electric pump 110V 60Hz
Additional weight of the electric pump
30
Kg
65
lbs
Electric pump power
1.5
kW
2
HP
Regime
1680
g/min
1680
rpm
Maximum current absorbed from the mains
21.6
A
21.6
A
(1) The weight of the machine may vary depending on the presence of optional accessories. Refer to the data on the machine
plate.
(2) Values refer to the raised platform.
(3) Values refer to the platform in transport position
