ALMACRAWLER JIBBI Series User Manual

PAGE22
2.1.5 Technical data JIBBI 1250 LTH version.
Technical data
Metric
Imperial
Lithium battery - LiFePO4
Machine weight (1)
2920
kg
6440
lbs
Battery nominal voltage
48
V
48
V
Battery nominal capacity
300
Ah
300
Ah
Battery weight
170
kg
375
lbs
Battery size
780 x 550 h
= 455
mm
31 x 22 h =
18
in
Battery Life (4)
≥2000
cycles
≥2000
cycles
Single-phase battery charger
48/20
V / A
48/20
V / A
Mains voltage for single-phase battery charger
110-230 /
50-60
V /
Hz
110-230 /
50-60
V / Hz
Maximum current absorbed by the charger
10.5
A
10.5
A
Maximum current delivered by the charger
20
A
20
A
Electric pump power
4
kW
5.4
HP
Max current absorbed by the electric pump
160
A
160
A
LWA sound power
87
dB A
87
dB A
Noise level of operator station Lp (internal industrial environment)
80
dB A
80
dB A
Noise level of operator station Lp (external environment on asphalt)
75
dB A
75
dB A
Hand / arm system vibrations (operator hands support)
<2.5
m /
s²
<2.5
m / s²
Whole Body Vibration (on platform - measured on level ground) (2)
0.52 ± 0.10
m /
s²
0.52 ± 0.10
m / s²
Hand / arm system vibrations (operator hands support) (3)
0.59 ± 0.10
m /
s²
0.59 ± 0.10
m / s²
Minimum operating temperature of the machine
-20
°C
-4
°F
Maximum operating temperature of the machine
+55
°C
+131
°F
Minimum temperature for recharging the lithium battery (5)
0
°C
32
°F
Maximum temperature for recharging the lithium battery
+55
°C
+131
°F
Performance:
Max slope that can be overcome in transport conditions
25
°
25
°
Maximum transfer speed in transport position
2.5
km /
h
1.6
mph
Maximum transfer speed with the platform in a high position
0.4
km /
h
0.2
mph
Full platform rise time
60
s
60
s
Full platform descent time
40
s
40
s
Optional single-phase 230V 50Hz electric pump
Additional weight of the electric pump
30
Kg
65
lbs
Electric pump power
2.2
kW
3
HP
Regime
1400
g/min
1400
rpm
Maximum current absorbed from the mains
14
A
14
A
Optional single-phase 230V 60Hz electric pump
Additional weight of the electric pump
30
Kg
65
lbs
Electric pump power
1.5
kW
2
HP
Regime
1620
g/min
1620
rpm
Maximum current absorbed from the mains
9.9
A
10
A
Optional single-phase electric pump 110V 50Hz
Additional weight of the electric pump
30
Kg
65
lbs
Electric pump power
1.85
kW
2.5
HP
Regime
1400
g/min
1400
rpm
Maximum current absorbed from the mains
28
A
28
A
Optional single-phase electric pump 110V 60Hz
Additional weight of the electric pump
30
Kg
65
lbs
Electric pump power
1.5
kW
2
HP
Regime
1680
g/min
1680
rpm
Maximum current absorbed from the mains
21.6
A
21.6
A
(1) The weight of the machine may vary depending on the presence of optional accessories. Refer to the data on the machine plate.
(2) Values refer to the raised platform.
(3) Values refer to the platform in transport position
(4) Declared value @ 80% DOD and timely maintenance
(5) At lower temperatures, the charging current is significantly reduced resulting in an increase in the overall charging time.
