2 TECHNICAL DATA, DIMENSIONS AND WORKING DIAGRAMS.
2.1 JIBBI 1250.
2.1.1 General technical data JIBBI 1250.
Dimensions:
Metric
Imperial
Maximum working height (1)
12.3
m
40' 4"
ft
Maximum height of the walking surface (1)
10.3
m
33' 9"
ft
Maximum working outreach from slewing bearing centre (1)
6.9
m
22' 7"
ft
Maximum platform capacity (m)
230
kg
500
lbs
Maximum number of people on the platform (n)
2
2
Mass of equipment and materials on the platform (me)
70
kg
150
lbs
Ground clearance of the carriage
120
mm
5
in
Turret rotation
220
°
220
°
Platform rotation
140
°
140
°
Max height of walking surface for safety speed insertion
1.62
m
5' 4"
ft
Maximum platform size - Standard
1.40 x 0.74
m
4'7"x2'5"
ft
Maximum platform size - Optional
1.80 x 0.74
m
5'11"x2'5"
ft
Track width with extended track
1.95
m
6' 5"
ft
Track width with retracted track
1.15
m
3' 9"
ft
Maximum transport length with platform mounted
3.83
m
12' 6"
ft
Maximum transport length with platform disassembled
3.12
m
10' 2"
ft
Minimum transport height
1.99
m
6' 6"
ft
Maximum Transport Width with Platform Mounted - Standard
1.40
m
4' 7"
ft
Maximum Transport Width with Platform Mounted - Optional
1.80
m
5' 11"
ft
Maximum transport width with platform disassembled
1.15
m
3' 9"
ft
Track dimensions (Height x Width) (2)
350 x 250
mm
13" x 9"
in
Hydraulic oil tank capacity
37
l
9.6
gal
Max. hydraulic pressure translation circuit
215
bar
3100
psi
Max hydraulic pressure lifting / lowering / rotation circuit
180
bar
2610
psi
Max. hydraulic pressure telescopic extension / retraction circuit
120
bar
1740
psi
Stability limits:
Max lateral slope of the terrain with elevated platform - wide track
15
°
15
°
Max longitudinal terrain slope with elevated platform - wide track
15
°
15
°
Maximum manual force allowed for 2 people on the platform (1)
400
N
90
lbf
Maximum manual force allowed for 1 person on the platform (1)
200
N
45
lbf
Maximum wind speed
12.5
m / s
28
mph
(1) Always refer to the working diagrams to obtain these data according to the different machine configurations.
(2) Standard black rubber tracks; Optional non-marking rubber tracks.
