- when the rotation plane of the fifth wheel is horizontal, the platform movement command is
activated.
Attention: RISK OF OVERTURNING
The system is not able to level the rotation plane of the fifth wheel if the ground is inclined over 15°
and, if the selector (5) is in the ON position, it is not possible to carry out any command to move the
platform.
It is necessary to position the selector (5) in the OFF position to be able to operate the controls to bring
the platform back to the ground and reposition the machine on suitable ground.
5.1.3.5 Winch control (optional).
Except for the JIBBI U-1570 model, on the other JIBBI 12xx and JIBBI16xx models, it is possible to install,
as INTERCHANGEABLE EQUIPMENT, a winch in place of the platform, allowing the machine to be used as
a crane for loads up to 200 kg. See specific instructions for installing the accessory.
Operate the switch (10) forward to raise the load, or backward to lower the load. The command is ON-
OFF, therefore it is not possible to modulate the manoeuvre speed, which occurs at a fixed speed set in
the factory.
The winch command cannot be performed at the same time as other commands.
Using the potentiometer (7) it is possible to vary the maximum control speed (ELC - LTH versions) or to
choose the rotation speed of the heat engine (versions with heat engine):
- Idle speed with potentiometer fully turned anticlockwise (-);
- Maximum speed with potentiometer fully turned clockwise (+).
