224
Wristband/roll paper (WB-S series)
When “Borderless Printing“ is disabled
Top, bottom, left. right margins: 1.5 mm (Typical value)
Do not print inside or within 2 mm {0.08"} around the snap button mounting hole to pre-
vent damage to the mechanical functions.
If using the WB-S/M/L series, use the attachment (OT-WA34).
Paper width
1.5 mm
Autocutting position
Paper feeding direction
Paper
1.5 mm
1.5 mm
Print area
5.5 mm
184.2 mm
11.0 mm
14.6 mm
81.5 mm
157.2 mm
105.9 mm
Recommended print area for text
and barcodes (*dimension)
72.5 mm
15.0 mm
12.4 mm
1.5 mm
30.2 mm
70.4 mm
7.9 mm
Black mark position
(back)
Blackmark position
(back)
36 mm
Center of paper width
Autocutting position
