Amada IS-300A - Page 96

IS-300A
9. External Communication Function
9-4
2) Error Data
Data strings:
!01 001:E03,04,12,15,17,19,22,26[CR][LF]
A B C D E F G H I J
A Device No. Fixed to 2 digits (01 to 31)
B Schedule No. Fixed to 3 digits (000 to 255)
C*
1
Error code 1 Fixed to 3 digits (E01 to E31)
D*
1
Error code 2 Fixed to 2 digits (01 to 31)
E*
1
Error code 3 Fixed to 2 digits (01 to 31)
F*
1
Error code 4 Fixed to 2 digits (01 to 31)
G*
1
Error code 5 Fixed to 2 digits (01 to 31)
H*
1
Error code 6 Fixed to 2 digits (01 to 31)
I*
1
Error code 7 Fixed to 2 digits (01 to 31)
J*
1
Error code 8 Fixed to 2 digits (01 to 31)
*1 The number of error codes is of eight max. In the case of only one error
code, the error codes D to J are omitted.
For error codes, see 13. (1) Fault Code List.
“E” is affixed only to Error code 1.
*2 Error codes are transmitted when errors are detected.
For the monitored value error and counter error, however, the error is
transmitted after the monitored data is transmitted.
