9. External Communication Function
9-5
 Bi-directional Communication Mode
(When <--> is selected at COMM CONTROL in the MODE SELECT screen)
Reading of trouble
Code: # Device No. R Schedule No. S Screen No. *
Example: Read all troubled data in the specified device, No. 01. (Schedule No. is
“008” and Voltage error and Electric power error are occurring.)
Host
#
I
D
1
I
D
2
R
S
H
1
S
H
2
S
H
3
S
S
C
1
S
C
2
*
C
R
L
F
0 1 * * * 0 7 : E18,19
0 1 0 0 0 0 7
!
I
D
1
I
D
2
S
H
1
S
H
2
S
H
3
S
S
C
1
S
C
2
: Data
C
R
L
F
IS-300A
1) In reading, Schedule numbers, SH1, SH2 and SH3 are fixed to 000.
In response, SH1, SH2 and SH3 are those of the last welding.
2) Screen numbers, SC1 and SC2 are fixed to 07.
3) In no trouble, data of “00” returned.
Error reset
Code: # Device No. W Schedule No. S Screen No. Data
Example: Resets the trouble of the specified device, No. 01.
Host
#
I
D
1
I
D
2
W
S
H
1
S
H
2
S
H
3
S
S
C
1
S
C
2
: Data
C
R
L
F
0 1 0 0 0 0 7 : 00
0 1 0 0 0 0 7 : E00
!
I
D
1
I
D
2
S
H
1
S
H
2
S
H
3
S
S
C
1
S
C
2
: Data
C
R
L
F
IS-300A
1) Schedule numbers, SH1, SH2 and SH3 are fixed to 000.
2) Screen numbers, SC1 and SC2 are fixed to 07.
3) “00” (no trouble) is returned as a confirmation data
