Page 16 of 100 Back-in-Box-Lift K70 / K90 / K90 ACTIVE
Figure 2: Back-in-Box-Lift K90 ACTIVE
Platform
Roll-off guard
Carrier
arms
Cassette
Hydraulic aggregate
Transfer
plate
