AMF-BRUNS K90 ACTIVE - Retracting the Platform into the Cassette

Emergency Mode
Page 50 of 100 Back-in-Box-Lift K70 / K90 / K90 ACTIVE
6.2.3 Retracting the platform into the cassette
ð Fully lower the platform (see Section 6.2.2, page 49).
ð Press the transfer plate down onto the platform.
ð Remove the relay cover (see Figure 34 and Figure 35).
Figure 34: Relay Cover
Figure 35: Removing the Relay Cover
ð Pull one of the two changeover relays out (see Figure
36).
Figure 36: Pulling the Changeover Relay Out
ð Raise the platform until it is at the same height as the
cassette (see Section 6.2.1, page 48).
Relay cover
Changeover re-
lay
Relay cover
