AMF-BRUNS K90 ACTIVE - Bluetooth Remote Control (Optional Extra)

Description
Page 24 of 100 Back-in-Box-Lift K70 / K90 / K90 ACTIVE
2.3.2 Bluetooth remote control (optional extra)
An optional Bluetooth remote control, that can replicate all
of the cable-connected remote control functions, is availa-
ble for the Back-in-Box-Lift (see Figure 16).
Figure 16: Bluetooth Remote Control, Operating Controls
Item
Designation
Function
1
"Retract" button
Retracts the platform into the
cassette.
Switch the Bluetooth remote
control ON (hold the button
pressed for longer than 3
seconds).
2
"Extend" button
Extends the platform from the
cassette.
3
“Lower” button
Lowers the platform.
4
“Raise” button
Raises the platform.
5
"Retract Position"
button
Brings the platform to the po-
sition from which it can be re-
tracted into the cassette.
The platform must be higher
than the cassette for this but-
ton to be effective.
7
8
9
3
2
1
5
4
6
USB connection
Cover
