Operation
Page 38 of 100 Back-in-Box-Lift K70 / K90 / K90 ACTIVE
5.3 Disembarkation Procedure
ð Switch the vehicle's engine OFF.
ð Remove the ignition key.
ð Apply the vehicle's handbrake.
ð Open the door, beneath which the Back-in-Box-Lift is
installed.
ð Take hold of the cable-connected remote control, Blue-
tooth remote control or Smartphone wit App installed.
ð Make certain that there are no persons within the range
of movement of the platform.
CAUTION!
Risk of injury through movements of the Back-in-Box-Lift.
There are a number of risks of personal injury if standing
within the danger zone.
Therefore:
• Only operate the Back-in-Box-Lift if there are no per-
sons standing within the danger zone.
•
Keep the danger zone under observation and stop the
Back-in-Box-Lift if any persons enter the danger zone.
ð Extend the platform from the cassette (for the operating
controls: see Section 2.3, page 23).
The warning signal sounds as soon as the platform starts
to extend. The blinkers on the sides of the platform blink.
The transfer plate folds upwards.
Once the platform is fully extended it will stop.
ð Release the remote control button as soon as the plat-
form has fully extended from the cassette.
ð Raise the platform until it reaches the height of the floor
inside the vehicle.
The transfer plate folds down to the horizontal and forms a
bridge between the floor inside the vehicle and the plat-
form.
ð Release the wheelchair's brakes.
ð If applicable, switch the motor of an electrically driven
wheelchair OFF.
ð Push the wheelchair onto the centre of the platform
ð Apply the wheelchair's brakes.
