Description
Back-in-Box-Lift K70 / K90 / K90 ACTIVE Page 15 of 100
2 Description
Persons who are wheelchair-bound can be embarked into
or disembarked from a vehicle using the Back-in-Box-Lift.
The main components of the Back-in-Box-Lift are:
• the platform,
• mechanics and hydraulics with carrier arms,
• the cassette and
• the operating controls.
The aim of this chapter is to illustrate the construction and
function of the Back-in-Box-Lift. To this end, the individual
assemblies and components are described in the following
sections.
2.1 Layout and Function
