AMF-BRUNS K90 ACTIVE - Retracting the Platform into the Cassette

Emergency Mode
Page 46 of 100 Back-in-Box-Lift K70 / K90 / K90 ACTIVE
6.1.4 Retracting the platform into the
cassette
ð Raise the platform until it is at the same height as the
cassette (see Section 6.1.2, page 44).
Or:
ð Lower the platform until it is at the same height as the
cassette (see Section 6.1.3, page 45).
ð Press the transfer plate downwards.
ð K70: Pull the changeover relay out (see Figure 28).
Figure 28: Pulling the Changeover Relay Out (K70)
ð K90: Pull one of the two changeover relays out (see
Figure 29).
Figure 29: Pulling the Changeover Relay Out (K90)
ð Manually push the platform fully into the cassette.
ð Make certain that the latch engages.
Changeover
relay
Changeover
relay
