Page 48 of 100 Back-in-Box-Lift K70 / K90 / K90 ACTIVE
6.2 Emergency Operation K90 ACTIVE
NOTE
Emergency operation is only possible if the platform is ex-
tended.
The emergency operating controls are located on the left-
hand side of the cassette (see Figure 30).
Figure 30: Emergency Operating Controls
6.2.1 Raising the platform
ð Insert the operating lever into the manually-operated
pump (see Figure 31).
ð Pump the lever up and down until the desired height is
reached.
Figure 31: Raising the Platform
Ball-cock
Manually-
operated
pump
Opening for
releasing the
latch
Manually-
operated
pump
Pump operat-
ing lever
