Description
Back-in-Box-Lift K70 / K90 / K90 ACTIVE Page 17 of 100
2.1.1 Platform
The platforms on the Back-in-Box-Lifts K70, K90 and K90
ACTIVE are of differing design:
With the K70 and K90, the wheelchair is pushed onto the
platform in the direction of the door of the vehicle, below
which the lift is installed (see Figure 3).
Figure 3: Back-in-Box Lifts K70 and K90, Platform Access
With the K90 ACTIVE, the wheelchair is pushed onto the
platform parallel to the vehicle, in the direction of the rear
of the vehicle (see Figure 4).
Figure 4: Back-in-Box-Lift K90 ACTIVE, Platform Access
All platforms are provided with a roll-off guard that auto-
matically rises when the platform is raised off the ground.
This prevents the wheelchair from rolling backwards off the
platform.
