AMF S-311 - LTT - Pneumatic System Connection

J X X X
A
A
J6A
J6B
J1B
J4B
J4A
J3B
J2B
J3A
J0A
J8A2
J8A1
J5B
J5A
J9B
4 bar
J7B
J7A
6 bar
4
7
1
3
5
9
2
6
J0A
8


S-311
1-16
Released:01/2014
E-mail: service@amfreece.cz; webside: amfreece.com
Phone: +420 582 309 146; Fax: +420 582 360 606
B - MACHINE ASSEMBLY
Tubes
identication
air distribution
0, 1, 2 — X => distribution from a regulator
0,1,2—Xpneumaticcylinderidentication
A ; B; C
1
clamp feet up/down
2
clamp feet spreading
3
upper thread draw-off
4
upper thread trimming
5
9
thread nipper
6
cutting
7
bottom thread
trimming CT
8
suction
S-311 LTT - PNEUMATIC SYSTEM CONNECTION
(therstnumberis0butisnotmarked)
