AMF S-311 - F - MACHINE MAINTENANCE; 1. MACHINE CLEANING AND MAINTENANCE







S-311
1-66
F - MACHINE MAINTENANCE
Released:01/2013
E-mail: service@amfreece.cz; webside: amfreece.com
Phone: +420 582 309 146; Fax: +420 582 360 606
Warning:
- Check electrical cables for damage.
- Check if the safety covers are in a good condition. Order or replace damaged covers.
- Keep your hands out from the needle space and cutting mechanism.
- Do not modify the machine in any way, which can eliminate its safety parts.
Caution:
- Do not neglect periodic maintenance.
- If you have fault in electrical power supply, switch off the operating switch (circuit breaker).
- Do not damage, correct and remove safety labels.
-Donotworkwiththemachinewhenyouareundertheinuenceofdrugsoralcohol.
- User has to ensure the lighting of the working area minimal 750 Luxes.
1. CLEANING AND MAINTENANCE OF THE MACHINE
1.1. Switch the power off and disconnect the air supply.
1.2. For cleaning and maintenance, remove the clamp
feet by removing the protecting latches
1
. Lift the clamp
feet and pull it to the operator. Remove the locking screw
3
and fold the rear cover
4
.
1.3. Clean the thread lints and fabric from the s e w i n g
area - guides and thread tension. To move the sewing
mechanism, turn the hand wheel
6
. It is also possible to
turn the race by hand. The machine head can be raised to
the position where it is locked by a strut which is
controlled by a button
5
. By pressing the button
5
, the
machine can lowered to the working position.
WARNING!
Possible serious injury when lowering the machine head.
1.4. Lubricate the machine according to the section F4.
1.5. Check if the oil reservoir
7
, under the machine, is
full. It is necessary to liquidate used oil according to the
environment regulation.
