AMF S-311 - Needle Installation

Recommended Threads
No.
Needle System
(Nm)
120 90
90 90 - 100
80 90 - 110
S-311
1-22
C - PROPER APPLICATION
Released:01/2014
E-mail: service@amfreece.cz; webside: amfreece.com
Phone: +420 582 309 146; Fax: +420 582 360 606
2. NEEDLE INSTALLATION
Use needles AMF Reece 02.0505.0.111/113…. Nm 90 – 110), loading Ø needle bard D = 2 mm. Needles 02.0558.1.112
are externally treated and needle shape is adapted for sewing thick material. Thicker needles is not possible to use
for standard stitching plates.
2.1. Lift the transparent needle cover up
1
.
2.2. Loosen the screw
2
and remove the needle.
2.3. Insert the new needle so that the needle scarf A is on opposite side from screw
3
of the tension. Do not install
abentorbrokenneedle.Rolltheneedleonaatsurfacetocheckforstraightness.
2.4. Tighten the screw
2
well.
