AMF S-311 - 9. CUTTING MECHANISM SETTINGS

S-311
1-35
Released:01/2014
E-mail: service@amfreece.cz; webside: amfreece.com
Phone: +420 582 309 146; Fax: +420 582 360 606
D - MACHINE CONTROLS
9. SETTING THE CUTTING
Cutting space, distance
between first and second
row of stitches
(range -0.2 - 1.2 mm)
Stitches distance from
cut to inner stitches
of the eye
(range -0.2 - 1.2 mm)
Buttonhole cut
correction in X axis
(range ± 1.5 mm)
Buttonhole cut
correction in Y axis
(range ± 1.5 mm)
Cutting time delay
(range ± 0 - 0,2 ms)
Return
to main display
Cutting indication
No cutting
Cut after sewing (CA) Cut before sewing (CB)
