AMF S-311 - Page 61

70 mm
64 -0,3 mm
X



Y
S-311
1-49
Released:01/2014
E-mail: service@amfreece.cz; webside: amfreece.com
Phone: +420 582 309 146; Fax: +420 582 360 606
E - STANDARD MACHINE ADJUSTMENT
8.3. The knife in the axis X in the anvil
6
loosing the screws
5
and change safely the position, to the right or to the
left. Tighten the screws.
8.4. The knife stop in the anvil
6
adjust for 70 mm after loosing the screws
7
.
8.5. The pressure of the pneumatic system is adjusted with the regulator
8
for 0,6 MPa. The pressure for cutting
knife is adjusted with the regulator
10
(0,4 MPa). This pressure is suitable for all materials for cut lengths to 30mm.
Fordifcultcut,increasethepressutefor1/2rotationanticlockwise.
8.6. The sensor
9
on the cutting cylinder is adjusted approx. for 43 ± 1mm (according the machine tolerances).
