Analog Devices ADAV4601 User Manual

ADAV4601 System Design Document Confidential Information
Rev.1 August 2009 Analog Devices Page 42
Analog In to Analog Out with audio processing and with Sub Channel coming to Analog Out
34 0100 1000 #Route AUXIN1 to Main
34 0122 FDC1 #Enable AVC, Lip Sync, EQ, Bass, Loudness, Limiter, Crossover.
34 0122 FDE1 #Add the tweeter and woofer channels together
34 0101 00E0 #Route Subchannel to AUXOUT1
34 0121 0022 #Unmute AUXOUT1 output and Main Tweeter/AUXOUT3 output
Analog In to PWM Out with audio processing
34 0100 1000 #Route AUXIN1 to Main
34 0122 FDC1 #Enable AVC, Lip Sync, EQ, Bass, Loudness, Limiter, Crossover.
34 0121 00C0 #Unmute Tweeter and Woofer
Digital In (I
2
S) to Digital Out (I2S) with audio processing
34 0100 3000 #Route SDIN0 to Main
34 0122 FC01 #Enable AVC, Lip Sync, EQ, Bass, Loudness
34 0101 D000 #Route Main (after loudness) to SDO
34 0121 0008 #Unmute SDO output
Digital In (I
2
S) to Digital Out (S/PDIF) with no audio processing
34 0101 0300 #Route SDIN0 to S/PDIF
34 0121 0004 #Unmute S/PDIF output
Analog In to Digital Out (S/PDIF) with no audio processing
34 0101 0100 #Route AUXIN1 to S/PDIF
34 0121 0004 #Unmute S/PDIF output
Digital In (I
2
S) to Analog Out with no audio processing
34 0101 0030 #Route SDIN0 to AUXOUT1
34 0121 0002 #Unmute AUXOUT1 output
