File Type Menu
Key Sequence: Shift > File (7) > Save Measurement > Change Type
Key Sequence: Shift > File (7) > Save > Change Type
Save Location Menu
Key Sequence: Shift > File (7) > Save > Change Save Location
JPEG Capture
Full Graph Only: Press this submenu key to toggle between file types, Full
and Graph Only. Choose Full to include all of the additional data on the
measurement screen. Choose Graph Only to capture just the measurement
trace in the sweep window.
Figure 4-14. File Type Menu
Sort By
Name Type Date: Press this submenu key to choose the item by which
folders are sorted in the Select Save Location list. See Figure 4-6
on page 4-5.
Sort Order
Ascend Descend: Press this key to toggle the sort order of the folder list
between Ascending and Descending.
Create Folder: Press this submenu key to create a new folder inside the
selected directory. Enter the new folder name in the Create Directory dialog
and press Enter. To return to the Select Save Location dialog without creating
a new folder, press Esc.
Set Location: Press this submenu key to set the currently selected folder as
the destination where saved files will be stored, and to return to the “Save
Menu” on page 4-11. Press Esc to exit without saving.
Refresh Directories: Press this key to update the folder list after connecting
or disconnecting an external USB drive.
Figure 4-15. Save Location Menu
File Type
JPEG Capture
Full Graph Only
Sort By
Name Type Date
Sort Order
Ascend Descend
Create
Folder
Set
Location
Refresh
Directories
Save Location
