9-3 Web Remote Control Interface Web Remote Control
9-6 PN: 10580-00252 Rev. K Site Master User Guide
Menu Bar
Remote Control
Opens “Remote Control” on page 9-7.
Capture Screen
Captures a JPEG image of the instrument display and saves it directly to internal memory. A
file name is automatically created using the current date and time stamp. Only the
instrument display will be pictured on the Web page under the menu bar. See Figure 9-4. In
Windows, you can right-click on the screen and select Copy. With iOS, press and hold on the
picture. This makes it easy to create documentation using screen captures.
Capture Trace
Opens an input dialog to enter a name for the trace to be saved. See Figure 9-5. After clicking
Save, a confirmation dialog opens to indicate the trace was successfully saved to the
instrument.
Figure 9-4. Capture Screen Page
Figure 9-5. Capture Trace Page
