Interference Analyzer (Option 25) 3-15 Measurements Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 3-53
C/I Signal Type Menu
Key Sequence: Measurements > Spectrum > Masks and > C/I > Carrier Signal Type
NB FHSS: Narrow Band Frequency Hopping Spread Spectrum. Use this
setting when the signal being measured is 802.11b.
WB FHSS: Wide Band Frequency Hopping Spread Spectrum. Use this
setting when the signal being measured is 802.11a or 802.11g.
Broadband: Use this setting when the signal being measured is a digital
modulation format such as CDMA and GSM.
Back: Returns to the “C/I Menu” on page 3-52.
Figure 3-47. IA C/I Signal Type Menu
NB FHSS
Broadband
WB FHSS
C/I Signal Type
Back
