3-4 W-CDMA/HSPA+ RF Measurements W-CDMA/HSPA+ Signal Analyzer
3-12 PN: 10580-00234 Rev. T 3GPP MG
Spectral Emission Mask Procedure
1. Set the measurement frequency using one of the methods listed in the User Guide.
2. Press the Measurements main menu key.
3. Press the RF Measurements submenu key.
4. Press the Spectral Emission Mask submenu key to activate the Spectral Emission Mask
measurement (Figure 3-5).
Figure 3-5. Spectral Emission Mask Measurement
