EVDO Signal Analyzer 3-14 Measurements Menu
3GPP2 MG PN: 10580-00235 Rev. D 3-27
ACPR Menu
Key Sequence: Measurements > RF Measurement > ACPR
Number of Carriers: Press this submenu key to set the number of main
channels from 1 to 5. Change the number of main channels with the arrow
keys or the rotary knob, then press the rotary knob or the Enter key. Or
change the number of channels by pressing a number on the numeric
keypad, press the Enter submenu key, and then press the Enter key. The
adjacent channels remain displayed.
Carrier BW (MHz): Press this submenu key to select a bandwidth of 1.23,
1.24, or 1.25 MHz.
Back: Returns to the “RF Measurement Menus” on page 3-26.
Figure 3-22. EVDO ACPR Menu
Number of
Carriers
Back
Carrier BW (MHz)
1.23 1.24 1.25
